Raw magnets (disc magnets) with a hole, made from NdFeB, high magnetic force

Raw magnets (disc magnets) with a hole, made from NdFeB, high magnetic force

Product description

Code: K2600
Manufacturer: Kipp
Prices: are listed at the bottom of the page in the product variant table, or upon request via the form below.
Delivery date:

typically approximately 7–10 days from the date of order, depending on the quantity and current stock availability in the central warehouse. Specific delivery dates are verified and confirmed by email on an individual order basis. If the goods are unavailable, the order may be cancelled. More information.
The shipping cost for consignments longer than 2 m is calculated based on actual values and, if necessary, adjusted subsequently.
zavřít

3D modely




Raw magnets (disc magnets) with a hole, made from NdFeB, high magnetic force | K2600

Specifikujte prosím do pole níže konkrétní objednací kód, ke kterému žádáte zaslat 3D model nebo si jej stáhněte z tabulky dostupných variant v dolní části stránky produktu a to tlačítkem 3D nebo Stáhnout.


Dear customers, we inform you in accordance with EU regulation that the information provided is not used or stored by us in any way and is only used to process this request. More information HERE
zavřít

Poptat cenu
Dear customers, we inform you in accordance with EU regulation that the information provided is not used or stored by us in any way and is only used to process this request. More information HERE

Download

Catalogue sheet Kipp K2600 Raw magnets (disc magnets) with a hole, made from NdFeB, high magnetic force Catalogue sheet Kipp K2600 Raw magnets (disc magnets) with a hole, made from NdFeB, high magnetic force

Detail zavřít

Clear filter
Order code Basic price excluding VAT Final price incl. VAT Order CAD Přídržná síla N Design / Version B D1‎ D2 H L L1
K2600.101003 upon request upon request Poptat cenu3D26A10±0,13,3±0,16,5±0,13±0,110±0,1—
K2600.151504 upon request upon request Poptat cenu3D50A15±0,13,3±0,16,5±0,14±0,115±0,1—
K2600.201003 upon request upon request Poptat cenu3D42A10±0,13,3±0,16,5±0,13±0,120±0,1—
K2600.202004 upon request upon request Poptat cenu3D70A20±0,13,3±0,16,5±0,14±0,120±0,1—
K2600.301003 upon request upon request Poptat cenu3D64A10±0,13,3±0,16,5±0,13±0,130±0,1—
K2600.301005 upon request upon request Poptat cenu3D69A10±0,13,2±0,16,5±0,15±0,130±0,1—
K2600.303004 upon request upon request Poptat cenu3D100A30±0,13,3±0,16,5±0,14±0,130±0,1—
K2600.401003 upon request upon request Poptat cenu3D90B10±0,13,3±0,16,5±0,13±0,140±0,130,4±0,1
K2600.401205 upon request upon request Poptat cenu3D100B12±0,14,6±0,19,8±0,15±0,140±0,125,7±0,1
K2600.501003 upon request upon request Poptat cenu3D119B10±0,13,3±0,16,5±0,13±0,150±0,140,8±0,1
The prices listed are basic for orders of 1 piece or more. For larger quantities, we will prepare an individual price quote for you.

❱
